TDP

25 W

NPU

N/A

Graphic card

C-960

Multi displays

Extended display

Interface

1 x HDMI-Out 4K @30Hz

1 x VGA-Out 1080P

Lan IC

RTL8111H

Lan Interface

100/1000Mbps

Lan Connector

1 x RJ45 Ports

Wireless Type

M.2 2230

Wireless Interface

2T2R WiFi6 /BT5.2

4G/5G

N/A

Serial Port

N/A

USB

2 x USB3.0,  4 x USB2.0

Button

1 x Power Button, 1 x Brightness+, 1 x Brightness-, 1 x Reset

SIM CARD

N/A

AUDIO

1 x 3.5mm Mic-In, 1 x 3.5mm Line Out

1 x 3.5mm Combo Jack (SIDE)

POWER

1 x 2.5/5.5 DC-IN Connector

Memory

2 x SO-DIMM DDR4, 8GB / 16GB

Storage

1 x 2280 NVME 128GB /256GB /512GB

OS

KYOS / UOS

LCD

23.8 inch, 1920*1080 IPS, LVDS

Camera

Optional 100W Magnetic Camera

Speaker

2 x 4¦¸ / 2.5W

Power Input

12v 2.5/5.5 DC-In

Dimension

540.8mm(L) x 422mm(W) x 175mm(H)

Operating Temp.

0~45¡æ

Operating Humidity

20%~90% non-condensing

Storage Temp

-20~60¡æ

Operating Humidity

10%~90% non-condensing
