N105
½ÓÄÉ Intel Adler Lake-N´¦Öóͷ£Æ÷£¬¾ß±¸¸»ºñµÄÍⲿ½Ó¿Ú£¬ÆÕ±éÓ¦ÓÃÓÚ¸ßЧ°ì¹«£¬½ÌÓý£¬ÕþÎñµÈ¡£
CPU | CPU | Intel? 12th Gen (Alder Lake N ) Celeron? Processors |
TDP | Up to 15W | |
Display | Graphic card | Intel? UHD Graphics |
Multi displays | Support 3 Displays | |
Interface | 2 x HDMI-Out, 1 x DP (from TYPE-C) | |
Network | Lan IC | 1 x Realtek Lan IC |
Lan Interface | 10/100/1000Mbps | |
Lan Connector | 1 x RJ45 Port | |
Wireless Type | WIFI5 | |
Wireless Interface | M.2 2230 Key E With PCIe,USB2.0 | |
4G/5G | N/A | |
I/O interface | Serial Port | N/A |
USB | 2 x USB3.2£¨Gen2£©£¬2 x USB2.0£¬ 2 x TYPE-C (USB3.2 Gen2) | |
Button | 1 x PowerButton, 1 x Clear CMOS Key | |
SIM CARD | N/A | |
AUDIO | 1 x 3.5mm Audio Jack (2 In 1) | |
POWER | 1 x 2.5/5.5 DC-IN Connector | |
System | Memory | 1 x SODIMM DDR4 3200Mhz£¬Max 16GB |
Storage | 1 x M.2 Key M 2280 for NVME/SATA SSD | |
OS | Windows 11/Linux | |
WatchDog | Support | |
Auto Power On | Support | |
RTC | Power on at specific time everyday | |
Power Input | 19v DC-In (2.5/5.5 DC Jack) | |
Dimension | 120mm(L) x 120mm(W) x 37mm(H) | |
Operating Temp. | 0~40¡æ | |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp | -20~70¡æ | |
Operating Humidity | 5%~95% non-condensing |
